Industrial measurement control instrument

Industrial measurement control instrument

    Unit Price: 20~500 USD
    Min. Order: 1 Piece/Pieces
    Packaging: Plywood Cartoon
    Productivity: 1000 pieces per mouth
    Brand: STMC,Sino Touch
    Transportation: Ocean,Land,Air,Express
    Place of Origin: Yantai,China
    Supply Ability: 1000 pieces per mouth
    Certificate: ISO9001
    HS Code: 90262010
    Port: YANTAI,QINGDAO,TIANJIN

Basic Info

Model No.: DI-1

Product Description

Industrial Display Instrument Product Overview:

HDM1100 Simple single loop digital display control High-precisionflow Meter, fool operation, a 0.3 magnitude measurement precision, seven new appearance size, double four LED display, can support the thermocouple, heat resistance, voltage (root operation), current (root operation) and input in the transmitter, suitable temperature, pressure, flow, liquid level, humidity, such as industrial process monitoring.It supports 2-way alarm function, 1-way transformer output or RS485 communication interface using standard MODBUS protocol, 1-way DC24V feed output, photoelectric isolation of input end, output end and power end, 100-240V AC/DC or 12-36V DC switching power supply, standard snap-in installation, working environment temperature is 0-50ºC, and relative humidity is 5-85%RH without condensation.


High-quality Display Instrument Features:
1. Industrial Control Display Instrument appearance structure drawing


(1) PV display window (measured value)
(2) SV display window
Display input type and other parameters in measurement state
Displays the set value in the parameter setting state
(3) First alarm (AL1) and second alarm (AL2) indicator light, RUN light and output light (OUT)
(4) Confirm key
(5) Shift key
(6) Reduced bond
(7) Increase the key
The meter core can be pulled out of the case, the method is to remove the lock on both sides of the front panel of the meter to the outside, and then grab the front panel of the meter to pull out, the table core and the case can be separated.In the back, the watch core inserted into the case must be pushed tight, and lock lock lock, in order to ensure protection standards.


Display Instrument6Display Instrument4

Outline dimensions and hole dimensions of the Led Display Instrument

Outline Dimension Hole Dimension Outline Dimension Hole Dimension
160*80mm
(Horizontal type)
152*76mm
48*96mm
(Vertical Type)
45*92mm
80*160mm
(Vertical Type)
76*152mm
72*72mm
(Quadrate Type)
68*68mm
96*96mm
(Quadrate Type)
92*92mm
48*48mm
(Quadrate Type)
45*45mm
96*48mm
(Horizontal type)
92*45mm
